Specifications:
Probe:
|
Diameter |
4mm/6mm |
|
Cable length |
1.5m |
|
DOF |
10mm-100mm |
|
Sensor |
HD image sensor |
|
Resolution |
HD 1000,000 pixels |
|
Working length |
Standard 1.5m,max 3m |
|
Material |
Abrasion resistant alloy |
|
Temperature |
No |
System:
|
Case size |
360 x 360 x 100mm |
|
Host size |
300 x 220 x 59mm |
|
Host weight |
1.9KG |
|
Host material |
Magnesium aluminum alloy |
|
Display Resolution |
1920 x 1200 |
|
Joystick Handle Size |
235 x 90 x 70mm |
|
Joystick handle weight |
0.4KG |
|
Articulation |
360° |
|
Bending angle |
<=150° |
|
storage |
Internal memory/sd card/U disk(optional) |
|
I/O Port |
Micro USB x 2 Mini HDMI x 1 SD slot x 1 Air plug x 1 |
|
Video output |
HDMI |
|
Light source |
Real cold light source + fiber |
Software:
|
Operation system |
Real-time intelligent multitasking operating system |
|
User interface |
Button + touch screen |
|
File management |
Intelligent file management system, support to the memory and sd card, USB storage media files and folders for the following operations: copy, cut, delete, rename and so on |
|
Image adjustment |
Display ratio adjustment(1:1 display, full screen display) resolution selection, camera parameter setting(brightness, contrast, gamma, chroma, saturation, sharpness) negative filter, digital zoom(5x digital), image freezing, real-time graffiti saving, call contrast |
|
Image zoom in /out |
3x |
|
Image format |
JPG |
|
Video format |
MP4 |
|
Text annotation |
Photo text overlay, can choose the font size of the annotation text |
|
Image annotation |
Seal(default/custom), doodle, text input |
|
Software upgrade |
On-site upgrades is available via sd card and USB storage media |
|
Language |
English/German/Spanish/Japanese/Traditional Chinese/Simplified Chinese/Russian/Korean |
