Specifications:
Technical parameters:
|
Model |
SZH401J |
|
Diameter |
4mm |
|
Pixels |
1MP |
|
DOF |
10-200mm |
|
FOV |
120° |
|
Light |
Optical fiber Light + LED Light |
|
Illuminance |
More than 12000 LUX |
|
Articulation |
360 Degree all way joystick rotation |
|
Probe Length |
Standard 1.5m cable, others can be customized. |
|
Working Temperature |
-30℃ ～80℃ |
|
Display |
5.2’’ IPS Touch Screen, resolution 1024×768 |
|
Display Size |
360*160*60mm |
|
Storage |
Built-in 64GB, 32GB U disk |
|
Interface |
Type-C (data interface)/USB2.0 (U disk, keyboard or mouse)/HDMI (external display)/3.5mm earphone/power supply DC (8.4V～12V/2A) |
|
Battery |
rechargeable lithium battery pack; available charged online, battery working time≥4 hours Battery: 8.4V/6800mAh |
|
IP Level |
Main Unit IP55, Insertion Tube IP67 |
|
Relative humidity |
Max90%，no condensation |
|
Operation System |
Android smart operating system |
|
Operation Method |
Full touch screen and operation keys |
|
File Management |
Picture-in-picture display on the same screen, take photo, recording video,dynamic browsing, screen freeze, image zoom, screen rotation, file renaming, text annotation,Negatives, photo editing, graffiti annotation |
|
Image/video Format |
JPEG(JPG)/MP4 |
|
System Language |
Chinese, English |
Accessory list:
|
Items |
Specifications |
Qty |
Unit |
|
1 |
Endoscope |
1 |
set |
|
2 |
U disk（32GB） |
1 |
pcs |
|
3 |
Charger |
1 |
pcs |
|
4 |
HDMI cable |
1 |
pcs |
|
5 |
Screw driver |
1 |
pcs |
|
6 |
Manual |
1 |
pcs |
