Specificaitons:

Insertion Tube parameters:

Image Sensor CMOS Image Sensor

Resolution (Dynamic/Static)

320(H) X 240(V)

720(H)x525(V)(N) / 720(H)x625(V)(P)

712 (H)x480(V)（N）/ 720(H)x576(V)(P)

Insertion Tube Tip Diameter : 5.5mm .

Frame Rate ~30 fps

Exposure Automatic

White Balance Fixed

Field-of View (FOV) :  80°

Depth-of-Field (DOF) : 10mm – 300 mm

System Magnification 8X at 15 mm

Light Source : 4 White LED

Working Temperature :  (-20°to 70°C)

Material of Tube :  Semi-rigid / Soft-metal

Extended Length :  1.0 M

Waterproof Standard :  IP67

DVM Specifications

 Power DC : 5V

Display : 3.5” TFT LCD Monitor 320 x 240 Pixels

Interface Mini :  USB 2.0 / AV Out

Battery Rechargeable: Li-Polymer Battery (3.7V)

Video Output Format :  NTSC & PAL

Recording Medium SD Card :  (Capacity up to 32G)

Still Image Storage Format JPEG :  (640 x 480)

Video Recording Storage Format :  AVI (320 x 240)

Language English + option : (Nine language)

Working/Storage Temperature :  (-20°to 60°C)

While Charging Battery Temperature:  ( 0°to 40°C)
